Description

Waveshare 9inch DSI Capacitive 10-Point Touch Display 720 1280 is a portrait IPS touch display designed for Raspberry Pi user interfaces, embedded control panels, industrial HMI projects, smart display terminals, and custom interactive devices. This 9-DSI-TOUCH-B module combines a 9-inch wide color gamut screen, 720 1280 resolution, 10-point capacitive touch, and a DSI interface in a slim format that works well for vertical display applications.

The display orientation is portrait by default. For projects that require horizontal layout, the software configuration can be adjusted for landscape display. This makes the screen a practical choice for dashboard systems, smart kiosks, wall-mounted control panels, and tablet-style embedded products.

Features

• 9-inch IPS display with 720 1280 resolution for sharp portrait-oriented interfaces.
• 10-point capacitive touch for responsive multi-touch control, depending on OS and software support.
• Wide color gamut LED technology delivers richer color performance and cleaner chroma.
• 6H toughened glass improves durability for frequent touch interaction.
• DSI interface supports high-speed display communication for compatible embedded platforms.
• Up to 60Hz refresh rate helps maintain smooth visual output.
• Software-adjustable backlight brightness allows easier adaptation to different lighting conditions.
• Aluminum alloy back cover and passive cooling structure support reliable long-term use.
• 160 wide viewing angle from the IPS panel helps keep content visible from different positions.

Specifications

Applications

• Raspberry Pi touch display projects for dashboards, media interfaces, and control panels.
• Smart home wall panels with portrait-oriented touch UI.
• Industrial HMI systems that need a larger interactive display surface.
• Embedded tablets and terminals for device control and information display.
• Retail, kiosk, and information panels with vertical visual layouts.
• Custom Linux and embedded GUI projects requiring a responsive DSI touch display.

Product List

1. 9-DSI-TOUCH-B 1
2. MIPI-DSI-Cable-12cm x1
3. MX 1.25 2PIN to 2.54 3PIN cable x1
4. FFC 22PIN cable ~200mm (opposite sides) x2
5. MX1.25 2PIN to MX1.25 4PIN cable ~150mm x1
6. Screws pack x1

Other Content

Connection examples are provided for Raspberry Pi 5, Raspberry Pi 4B, ESP32-P4-NANO, Luckfox Omni3576, and Luckfox Lyra, which helps speed up integration for embedded touch display projects.

For related setup and platform guidance, you can also review OpenELAB articles on Raspberry Pi 5 getting started and Raspberry Pi configuration.

Controller boards and hosts shown in the connection diagrams are for reference only and are not included in the package.

Resources

• Waveshare wiki: 9-DSI-TOUCH-B
• Raspberry Pi getting started documentation
• Raspberry Pi configuration documentation
• Raspberry Pi official documentation center
• Luckfox documentation center

FAQ

Q: Is this display portrait or landscape by default?
A: The display is portrait by default with 720 1280 resolution. Software configuration can be changed for landscape use when needed.

Q: Does this screen support multi-touch?
A: Yes. It supports up to 10-point capacitive touch, depending on the operating system and software environment.

Q: Is this suitable for Raspberry Pi projects?
A: Yes. It is designed for DSI-connected embedded platforms and is commonly used in Raspberry Pi display applications.

Q: Are the Raspberry Pi or other controller boards included?
A: No. The controller boards shown in the official connection images are not included.
