Features:

• DC Voltage: 12V DC
• Current : 5A
• Ripple & Noise: 80MV
• DC Adjustable Range: 10%
• Rated Voltage Voltage Tolerance: 2.0%
• Line Regulation: 0.5%
• Load Regulation: 1% Setup,Rise Time,Hold Up Time:200ms,50ms, 20ms/230VAC AC
• Voltage Range: 85-264VAC
• Frequency Range: 47-63Hz
• Efficiency:85%
• AC Current: 0.86/115V 0.4A/230V
• AC Inrush Current: 20A/115V 40A/230V
• Leakage Current< 0.5mA /240VAC
• Over-load: 105%-150% hiccup mode,Auto-recovery
• Over-voltage: 115%-135% Cut Off the Output,Auto-recovery
• Over-temp. : Shut down O/P voltage, Auto-recovery
• Working temp.: -10~ +60C (Refer to output load derating curve)
• Working Humidity:20 ~ 90% RH, non-condensing
• Storage Temp.: -10~ +60C
• Storage Humidity: 10 ~ 95% RH
• Isolation Resistance:I/P-O/P,I/P-FG,O/P-FG:100M Ohms/500VDC / 25C/ 70% RH
• Withstand Voltage: I/P-O/P:3KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC
• Safety standards: CE,RoHS,FCC,ISO9001
