*Standard package contents may differ based on standard order codes.
| Feature |
Details |
| Mobile Module |
4G LTE Cat 4 (up to 150 DL/50 UL Mbps), 3G (up to 21 DL/5.76 UL Mbps), 2G (up to 236.8 DL/236.8 UL kbps) |
| 3GPP Release |
Release 9 |
| SIM Switch |
2 SIM cards, auto-switch cases: weak signal, data limit, SMS limit, roaming, no network, network denied, data connection fail, SIM idle protection |
| Status |
IMSI, ICCID, operator, operator state, data connection state, network type, bandwidth, connected band, signal strength (RSSI, SINR, RSRP, RSRQ), EC/IO, RSCP, data sent/received, LAC, TAC, cell ID, ARFCN, UARFCN, EARFCN, MCC, and MNC |
| SMS |
SMS status, SMS configuration, send/read SMS via HTTP POST/GET, email-to-SMS, SMS-to-email, SMS-to-HTTP, SMS-to-SMS, scheduled SMS, SMS auto-reply, SMPP |
| USSD |
Sending and reading Unstructured Supplementary Service Data (USSD) messages |
| Black/White List |
Operator black/white list by country or separate operators |
| Multiple PDN |
Use different PDNs for multiple network access and services |
| Band Management |
Band lock, used band status display |
| SIM Idle Protection Service |
SIM cards remain idle when not in use |
| SIM PIN Code Management |
Set, change, or disable SIM PIN |
| APN |
Auto APN |
| Bridge |
Direct connection (bridge) between mobile ISP and device on LAN |
| Passthrough |
Assign routers mobile WAN IP to another device on LAN |
| Feature |
Details |
| Wireless Mode |
802.11b/g/n (Wi-Fi 4), Access Point (AP), Station (STA) |
| Wi-Fi Security |
WPA2-Enterprise, WPA3, OWE, AES-CCMP, TKIP, client separation, EAP-TLS with PKCS#12 certificates |
| SSID/ESSID |
SSID stealth mode, access control via MAC address |
| Wi-Fi Users |
Up to 100 simultaneous connections |
| Wireless Connectivity Features |
Fast roaming (802.11r), Relayd, BSS transition management (802.11v), radio resource measurement (802.11k) |
| Wireless MAC Filter |
Allowlist, blocklist |
| Wireless QR Code Generator |
Enables network access via QR code |
| TravelMate |
Forward Wi-Fi hotspot landing page to subsequent devices |
| Feature |
Details |
| Routing |
Static routing, Dynamic routing (BGP, OSPF v2, RIP v1/v2, EIGRP, NHRP), Policy-based routing |
| Network Protocols |
TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, SFTP, FTP, SMTP, SSL/TLS, ARP, VRRP, PPP, PPPoE, UPNP, SSH, DHCP, Telnet, SMPP, SNMP, MQTT, Wake On LAN (WOL), VXLAN |
| VoIP Passthrough Support |
H.323 and SIP-ALG protocol NAT helpers for proper VoIP packet routing |
| Connection Monitoring |
Ping Reboot, Wget Reboot, Periodic Reboot, LCP and ICMP link inspection |
| Firewall |
Port forward, traffic rules, custom rules, TTL target customization |
| Firewall Status Page |
View firewall statistics, rules, and rule counters |
| Ports Management |
View and manage device ports: enable/disable, auto-configuration, transmission speed settings |
| Network Topology |
Visual representation of connected devices and their network relationships |
| Hotspot |
Captive portal, Radius server, SMS authentication, customizable landing pages, user scripts, themes |
| DHCP |
Static/dynamic IP allocation, DHCP relay, server configuration, static leases (MAC with wildcards) |
| QoS / Smart Queue Management (SQM) |
Traffic priority by source/destination, service, protocol, or port, WMM, 802.11e |
| DDNS |
Supported for >25 service providers; manual configuration available |
| DNS over HTTPS |
Secure DNS resolution via HTTPS proxy |
| Network Backup |
Wi-Fi WAN, Mobile, VRRP, Wired options for automatic failover |
| Load Balancing |
Balance internet traffic across multiple WAN connections |
| SSHFS |
Remote file system mounting via SSH protocol (not available in standard firmware) |
| Traffic Management |
Real-time monitoring, wireless signal charts, traffic usage history |
| Port Mirroring |
Mirror Ethernet traffic for monitoring and analysis |
| Feature |
Details |
| Authentication |
Pre-shared key, digital certificates, X.509 certificates, TACACS+, Internal & External RADIUS users authentication, IP & login attempts block, time-based login blocking, built-in random password generator |
| Firewall |
Preconfigured firewall rules via WebUI, unlimited configuration via CLI, DMZ, NAT, NAT-T, NAT64 |
| Attack Prevention |
DDOS prevention (SYN flood, SSH, HTTP/HTTPS attack prevention), Port scan prevention (SYN-FIN, SYN-RST, X-mas, NULL flags, FIN scan attacks) |
| VLAN |
Port and tag-based VLAN separation |
| Mobile Quota Control |
Mobile data limit, customizable period, start time, warning limit, phone number |
| Web Filter |
Blacklist for unwanted websites, Whitelist for allowed websites |
| Access Control |
Flexible access for SSH, Web interface, CLI, and Telnet |
| SSL Certificate Generation |
Let’s Encrypt and SCEP certificate generation methods |
| VPN Protocol |
Details |
| OpenVPN |
Multiple clients and server support, 27 encryption methods |
| OpenVPN Encryption |
DES-CBC 64, RC2-CBC 128, DES-EDE-CBC 128, DES-EDE3-CBC 192, DESX-CBC 192, BF-CBC 128, RC2-40-CBC 40, CAST5-CBC 128, RC2-64-CBC 64, AES (128/192/256) GCM, CFB, CFB1, CFB8, OFB |
| IPsec |
XFRM, IKEv1, IKEv2, with 14 encryption methods (3DES, DES, AES128/192/256, AES128GCM8/12/16, AES192GCM8/12/16, AES256GCM8/12/16) |
| GRE |
GRE tunnel and GRE over IPsec support |
| PPTP/L2TP |
Client/Server support, L2TPv3, L2TP over IPsec |
| Stunnel |
Proxy adding TLS encryption without code changes |
| DMVPN |
Scalable IPsec VPNs, Phase 2 and 3, Dual Hub support |
| SSTP |
SSTP client instance support |
| ZeroTier |
ZeroTier VPN client support |
| WireGuard |
WireGuard VPN client and server support |
| Tinc |
Tinc with encryption, authentication, and compression; Client and server support |
| Feature |
Details |
| WEB UI |
HTTP/HTTPS, status, configuration, FW update, CLI, troubleshoot, multiple event log servers, firmware update availability notifications, event log, system log, kernel log, Internet status |
| FOTA |
Firmware update from server, automatic notification |
| SSH |
SSH (v1, v2) |
| SMS |
SMS status, SMS configuration, send/read SMS via HTTP POST/GET |
| Call |
Reboot, Status, Mobile data on/off, Output on/off, answer/hang-up with a timer, Wi-Fi on/off |
| TR-069 |
OpenACS, EasyCwmp, ACSLite, tGem, LibreACS, GenieACS, FreeACS, LibCWMP, Friendly tech, AVSystem |
| MQTT |
MQTT Broker, MQTT publisher |
| SNMP |
SNMP (v1, v2, v3), SNMP Trap, Brute force protection |
| JSON-RPC |
Management API over HTTP/HTTPS |
| RMS |
Teltonika Remote Management System (RMS) |
| Platform |
Features |
| ThingWorx |
Monitor WAN Type, WAN IP, Mobile Operator Name, Mobile Signal Strength, Mobile Network Type |
| Cumulocity – Cloud of Things |
Monitor Device Model, Revision, Serial Number, WAN Type and IP, Mobile Cell ID, ICCID, IMEI, Connection Type, Operator, Signal Strength. Includes reboot and firmware upgrade actions |
| Azure IoT Hub |
Configurable with Data to Server to send available parameters to the cloud. Supports Direct method for RutOS API calls. Plug and Play integration with Device Provisioning Service |
| AWS IoT Core |
Utility to interact with AWS cloud platform. Supports AWS Jobs functionality for device API calls |
| Category |
Details |
| Ethernet |
4 x RJ45 ports, 10/100 Mbps |
| I/O’s |
1 x Digital Input, 1 x Digital Output on 4-pin power connector |
| Status LEDs |
1 x Bi-color connection status, 5 x Mobile connection strength, 4 x ETH status, 1 x Power |
| SIM |
2 x SIM slots (Mini SIM – 2FF), 1.8 V/3 V, external SIM holders, eSIM (optional, different hardware required) |
| Power |
1 x 4-pin power connector |
| Antennas |
2 x SMA for LTE, 2 x RP-SMA for Wi-Fi antenna connectors |
| Reset |
Reboot/User default reset/Factory reset button |
