Raspberry Pi 500
Shopping information
Raspberry Pi 500 is a fast, powerful computer built into a high-quality keyboard, for the ultimate compact PC experience – now with a 32GB MicroSD card included!
It features the same quad-core 64-bit Arm processor and RP1 I/O controller found in Raspberry Pi 5, and 8GBRAM! With a one-piece aluminium heatsink built-in for improved thermal performance, your Raspberry Pi 500 will run fast and smoothly even under heavy load, while delivering glorious dual 4K display output.
Technical specifications aside, a few subtle changes have been made compared to Raspberry Pi 400 – such as the repositioned USB ports and new power button functionality which works the same as the Raspberry Pi 5 button. It’s now also all-white –which we think looks dead smart!
You may also need…
Raspberry Pi 500comes with a 32GB Raspberry Pi A2-Class Micro-SD card, the recommended SD card for all Raspberry Pi computers.
You will need to add your own 27W power supply, Micro-HDMI cable, mouse and monitor.
Don’t forget, the Raspberry Pi 500 has an RJ45 Ethernet port, so grab an Ethernet cable if you plan to hard-wire your internet/LAN connection instead of using the onboard WiFi.
Desktop Kit Available
For those looking for the complete Raspberry Pi 500 setup, the Raspberry Pi 500 Desktop Kit comes with a mouse, a USB-C power supply and an HDMI cable, along with the Official Raspberry Pi Beginners Guide, to help you get the most out of your new computer.
Raspberry Pi 500 Accessories
Check out our Raspberry Pi 500 accessories section for a range of goodies to go with your new favourite computer – such as our great-value Sleeve for Raspberry Pi 500!
Raspberry Pi 500 Features
| Processor | 2.4GHz quad-core 64-bit Arm Cortex-A76 CPU, with cryptography extensions |
| 512KB per-core L2 caches and 2MB shared L3 cache | |
| Memory | 8GB LPDDR4X-4267 SDRAM |
| Connectivity | Dual-band (2.4GHz and 5.0GHz) IEEE 802.11b/g/n/ac Wi-Fi |
| Bluetooth 5.0, BLE | |
| Gigabit Ethernet | |
| 2x USB 3.0 ports and 1x USB 2.0 port | |
| GPIO | Horizontal 40-pin GPIO header |
| Video & sound | 2x micro HDMI ports (supports up to 4Kp60) |
| Multimedia | H.265 (4Kp60 decode) |
| OpenGL ES 3.0 graphics | |
| SD card support | MicroSD card slot for operating system and data storage |
| Keyboard | 78-, 79- or 83-key compact keyboard (depending on regional variant) |
| Power | 5V DC via USB connector |
| Operating temperature | 0C to +50C |
| Dimensions | 286mm x 122mm x 23mm (maximum) |
| Production lifetime | Raspberry Pi 500 will remain in production until at least January 2034 |
| Compliance | For a full list of local and regional product approvals, please visit pip.raspberrypi.com |
| Product Number | United Kingdom = Raspberry Pi SC1230 |
| United States = Raspberry Pi SC1231 | |
| EAN | United Kingdom = 5056561804248 |
| United States = 5056561804255 |
Resources
- Raspberry Pi 500 Announcement Blog Post
- Raspberry Pi 500 Product Brief
- Raspberry Pi 500 Documentation
Package Contents
- 1x Raspberry Pi 500 (select layout before adding to cart)
- Includes a 32GB Raspberry Pi A2-Class MicroSD Card Pre-programmed with Raspberry Pi OS
Power supply, HDMI cables, mouse and monitor not included
