Features:

• Program all MSP430Fxxx flash microcontrollers
• Ultra fast programming 14KB/s faster several times than TI-USB-FET (1.4 KB/s with spy-bi-wire)
• Uses TI standard 2×7 pin JTAG connector
• Spy-By-Wire support for the newest TI MSP430 devices
• Can supply target with 3.3V fixed voltage 50mA maximum current, no short circuit protection(!)
• MSP430.dll makes it compatible with all existing software which works with TI-USB-FET (emulates TI-USB-FET)
• Compatible with IAR Kickstart software for programming, real time emulation, debugging, step by step program execution, breakpoints, memory dump etc everything all high priced emulators do
• With IAR Kickstart you can write in assembler unlimited code size and to write in C with 2K limit for all MSP430 microcontrollers
• Works with free GCC C compiler and Insight MSP430 toolchain and debugger
• For MAC-OS users: reported to work with PS X 10.4 and current Parallels
• Dimensions 50×40 mm (2×1.6″) + 20 cm (8″) cable

Documents:

• How to install Olimex USB MSP430 programmers
• SPY-BI-WIRE connection please pay attention if you want to use SBW devices as the JTAG connection is differ
• How to install and use Olimex JTAGs with CCS 4.x
• How to install and use Olimex JTAGs with CrossWorks

Hardware:

• MSP430-JTAG-TINY connector (top view)

Software:

• Windows drivers + MSP430-JTAG-TINY-V2 firmware version 2.005
• OLIMEX MSP430-PROGRAMMER – GUI 1.3.0.4_CLI 2.0.1.2_DLL1.0.4.2/ 17.11.2011 freeware – stand alone software which allow you to program MSP430 devices without any 3rd party
• MSP430 JTAG drivers ver.1.0.4.2 -26-JUL-2011 add support for all devices released by TI to July 2011
• MSP430 dll ver.1.0.4.1
• MSP430 JTAG drivers ver.1.0.3.9
• MSP430 Kick Start C compiler and debugger (free for assembly language, limited for C)
• MSPGCC – free C compiler and debugger
• MSPdebug support for Linux for MSP430-JTAG-TINY made by Daniel bear, tested to work fine in both JTAG and SBW mode with MSPdebug 0.16
