Specifications:

• Conversion efficiency: Up to 92% (output voltage higher, the higher the efficiency)
• Switching Frequency: 150KHz
• Rectifier: Non-Synchronous Rectification
• Module Properties: Non-isolated step-down module (buck)
• Short circuit protection: current limiting, since the recovery
• Operating temperature: Industrial grade (-40 to +85 ) (output power 10W or less)
• Load regulation: 0.5%
• Voltage regulation: 2.5%
• Full load temperature rise: 40
• Input voltage: 4-35V
• Output voltage: 1.23-30V(Adjustable)
• Output current: Rated current is 2A, maximum 3A(Additional heatsink is required)
