The LILYGO T-Display AMOLED Lite is a compact, high-performance development board powered by the ESP32-S3R8 dual-core LX7 microcontroller. It features a vibrant 1.47-inch RM67162 IPS AMOLED display with a capacitive touch interface, making it ideal for IoT interfaces, smart controls, and embedded display projects. With full support for Wi-Fi, Bluetooth 5, and popular platforms like Arduino, PlatformIO, and MicroPython, this board offers rich functionality in a small footprint.

Key Features

• Built-in ESP32-S3R8 dual-core LX7 processor

• 2.4 GHz Wi-Fi and Bluetooth 5 (LE) connectivity

• 1.47-inch IPS AMOLED touch display with RM67162 driver IC

• Supports QSPI interface for high-speed data transmission

• 16MB Flash and 8MB PSRAM

• Onboard Boot, Reset, Power buttons and GPIO access (IO21)

• 3D Antenna and external antenna support

• Compatible with STEMMA QT / Qwiic interface (JST-SH 1.0mm 4-Pin)

• Ideal for portable GUI displays, sensor dashboards, and wearable interfaces

Pinout & Interface

• Supports GPIO, ADC, DAC, UART, I2C, SPI, Touch, and Power management

• Clearly labeled pin map for easy development

• Compatible with both 3D antenna and external antenna

Package Includes

• 1 x T-Display AMOLED Lite Board

• 2 x 12-pin Male Header Pins

• 1 x Power Cable (2-pin JST 1.25mm)

Technical Specifications

Display 1.47 inch RM67162 IPS AMOLED

Suggested Applications

• Smartwatch or wearable displays

• IoT device dashboards

• Touch GUI prototypes

• Portable embedded interfaces

• Sensor control panels

References

T-Display AMOLEDLite
