Product features

Input Voltage Range: AC50V-277V DC70V-390V

No-load Power: < 0.05W Full Load Power: < 4W

Output Characteristics: Multiple modules with the same voltage can be connected in parallel to meet the demand for high current in a small space.

Output Voltage

• The output voltage is 5V 0.15V at both no-load and full-load conditions.
• The voltage decreases by 0.1V under light load and recovers under heavy load.
• At 50% load, the ripple is 60mV.

Output Current

• The output current range is 5V 0mA-700mA, and it operates in constant current mode at full load.

Test Resistance

• A 7-ohm test resistance is used to test the 5V voltage (actual voltage is 4.9V).

Output Indicator: Green light.

Output Power: 3.5W with an efficiency of approximately 80%.

Output Protection: Overvoltage, overcurrent, overtemperature, over power, and short circuit protection.

Operating Temperature: -20C to 70C. High-grade models with green gold capacitors can withstand temperatures up to 105C for 10,000 hours. Lifespan is greater than 5 years at 70C and approximately 20-50 years at room temperature (not recommended for use above 70C). Output filtering is done with high-quality solid-state capacitors.

Product dimensions
