Features:

• Tactile response is performed directly by larger contact pressure to ensure very stable contact.

• All plastics are UL 94V-0 grade fire retardant.

• Bottom epoxy sealed standard to ensure free of flux immersion during wave soldering.
• Contact wiping on make and break.
• Gold plated contacts to ensure low contact resistance and long mechanical life.
• Ideal for data processing, communications, remote controls and burglar alarm system use, where manual programming is required.

Specifications:

1.Electrical

• Contact rating: 25mA 24VDC (switching) ; 100mA (non-switching)

• Contact resistance: 50m Max. (initial) ; 100m Max. (after life test)

• Insulation resistance: 1000M Min. at 100VDC

• Dielectric strength: 500VDC Min. for 1 minute
• Capacitance between adjacent switches 5pF Max.


2.Mechanical and environmental

• Operating temperature: -25C to + 70C

• Storage temperature: -40C to + 85C

• Operation force: 800g Max.

• Mechanical life: 2000 operations

• Humidity: 95RH, 40C for 96 Hrs.

• Vibration: Per MIL-STD-202F, method 204D

• Solderability: After flux 2305C for 50.5 seconds, 95% coverage

• Resistance to soldering heat: 2605C for 51 seconds

Applications:

• Numerical setting for computer terminal equipment

• Price setting for vending machines

• Programming for game machines

• Programming for industrial equipment and measuring instruments
