APPLICATION:
Shielded Plenum Broadcast & Security Cable is suitable for use on public address systems, intercoms, audio, internal telephones, remote controls, sound circuits and burglar/security systems. CL3P rated cable is for applications installed in air return plenums or where the limiting of smoke transmission is required and with voltages not to exceed 300 volts.

CONDUCTORS:
Stranded soft drawn bare copper conductor.

SHIELD:
Overall polyester backed aluminum foil, with a 24AWG tinned copper drain wire.

CONDUCTOR COLORS:
Black, Red, White, and Green.

JACKET COLOR:
White

JACKET:
Low smoke polyvinyl chloride (PVC) jacket suitable for use from -20C to +60C

INSULATION:
Low smoke polyvinyl chloride (PVC) color coded insulation

All values are nominal and subject to correction.
